Mortarboard and tassel. The wall is one strip of plywood with a living hinge cut into it, so the whole outline wraps from a flat sheet. Set the size in millimetres, pick a hinge pattern and a lid, watch it fold in 3D, then export the cut file for your laser.

Open the Graduation Cap in the Studio See Pro pricing

Pro shape: preview and fold it free, export from $9 a month or $149 once.

Graduation Cap box: a 3D render of the laser-cut living-hinge box in Baltic birch with its scored lid drawing

At the suggested size

189 × 120 × 80 mm on 3 mm plywood

These numbers come from the same engine that makes your file, built at the size the Studio suggests with the Straight Lattice hinge. Change the size, stock or pattern and they update live.

parts
6
on 2 sheets of 420 × 297 mm
of cutting
20.9 m
599 hinge cuts
wall length
521 mm
in 2 strips that butt-joint
tightest bend
R9 mm
rounded to suit 3 mm stock
hinge load
91%
of the safe twist limit
lid art
Scored
a matching line drawing on the lid
Graduation Cap lid as the laser sees it: red cut outline and blue scored lid art
The lid, as the laser sees it. Red is the cut, blue is the scored lid art. Turn lid art off in the Assembly tab for a plain lid.
Three lids

Drop-in, Snap-lock, Magnetic Lip. Every lid works with every shape.

Three stocks

3 mm, 4 mm, 6 mm. Hinge spacing and corner radii follow the thickness.

Kerf-compensated

Tabs grow and slots shrink by half your kerf, so parts press-fit without sanding.

Hinge patterns

Hinges that suit a graduation cap

Any of the 21 patterns works on this shape; the cut spacing adapts to each curve of the wall. These four suit the Birthdays, babies and graduations collection. Each link opens the Graduation Cap with that hinge.

Zipper cut layout: red cut lines and blue score lines
ZipperPro
Interlocking square teeth
Chevron cut layout: red cut lines and blue score lines
ChevronPro
Nested V stripes
Heartbeat cut layout: red cut lines and blue score lines
HeartbeatPro
Pulse line with a spike
Ripple cut layout: red cut lines and blue score lines
RipplePro
Waves that roll diagonally

Zipper: Interlocking square teeth. Sewing and fashion gifts, toolboxes, a playful look on kids’ boxes.

Before you cut

From file to finished box

Import the SVG at 1:1, give the blue layer a light score pass and the red layer a full cut, score first, then cut. The guides cover settings by machine and material, assembly, and selling what you make.
