Shield living-hinge box

A heater shield with a point at the bottom. Awards, medals, knightly party favors.

Heater shield with a point. The wall is one strip of plywood with a living hinge cut into it, so the whole outline wraps from a flat sheet. Set the size in millimetres, pick a hinge pattern and a lid, watch it fold in 3D, then export the cut file for your laser.

Open the Shield in the Studio See Pro pricing

Pro shape: preview and fold it free, export from $9 a month or $149 once.

Shield box: a 3D render of the laser-cut living-hinge box in Baltic birch with its scored lid drawing

At the suggested size

140 × 160 × 80 mm on 3 mm plywood

These numbers come from the same engine that makes your file, built at the size the Studio suggests with the Straight Lattice hinge. Change the size, stock or pattern and they update live.

parts
6
on 2 sheets of 420 × 297 mm
of cutting
14.5 m
370 hinge cuts
wall length
487 mm
in 2 strips that butt-joint
tightest bend
R10 mm
rounded to suit 3 mm stock
hinge load
89%
of the safe twist limit
lid art
Border
an inset line around the lid
Shield lid as the laser sees it: red cut outline and blue scored lid art
The lid, as the laser sees it. Red is the cut, blue is the scored lid art.
Three lids

Drop-in, Snap-lock, Magnetic Lip. Every lid works with every shape.

Three stocks

3 mm, 4 mm, 6 mm. Hinge spacing and corner radii follow the thickness.

Kerf-compensated

Tabs grow and slots shrink by half your kerf, so parts press-fit without sanding.

Hinge patterns

Hinges that suit a shield

Any of the 21 patterns works on this shape; the cut spacing adapts to each curve of the wall. These four suit the Geometric collection. Each link opens the Shield with that hinge.

Interlocking Hex cut layout: red cut lines and blue score lines
Interlocking HexFree
Mirrored zig-zags
Diamond Lattice cut layout: red cut lines and blue score lines
Diamond LatticePro
Mirrored Vs form diamonds
Battlement cut layout: red cut lines and blue score lines
BattlementPro
Square-wave castle steps
Stepped Lattice cut layout: red cut lines and blue score lines
Stepped LatticePro
Three-phase stagger

Interlocking Hex: Mirrored zig-zags that lock into a field of hexagons. A honeycomb look on hexagon and round boxes, and a stiffer feel in the hand than straight slots.

Before you cut

From file to finished box

Import the SVG at 1:1, give the blue layer a light score pass and the red layer a full cut, score first, then cut. The guides cover settings by machine and material, assembly, and selling what you make.
